Masterlink Universal Add-on 4/5 Axis Drive Control System

Views:









For universal FANUC system
4/5 axis drive control integrated
►Customised Mcizak O makiimo bfOtiiGf system
4/5 axis drive control integrated
►MU1X servo drive integrated
► Easy and fast installation and commissioning
Comparison table between conventional applications and MasterLink universal 4/5 axis drive control:

Content General		MasterLink
Number of additional axes available	4/5 axis	9 axis
Installation and commissioning time	8H	4H
Performance	Linkable	Arbitrary angle positioning (O.OOldeg)
Running speed	_To	Speed can be adjusted at will
Connection method	Adjustment of a large number of parameters, PLC	Only one I/O point required
